SINGLE ACTING AIR RELEASE VALVE

 Air bubbles enter the valve and displace the liquid inside, lowering the liquid level. When the level drops to where it no longer buoys the float, the float drops. This motion pulls the seat away from the orifice, triggering the valve to open and vent the accumulated air into the atmosphere.

SINGLE ACTING AIR RELEACE VALVE (SMALL ORIFICE)

For automatically releasing air which may accumulate under pressure in a section of pipe line during normal working condition.

Specifications

Brand                                  : Floin

Model                                  : AR101

Size                                      : 15 TO 40 NB

Connection                      : Flanged/screwed

Mounting                          : Top

Material                             : CI/WCB/CF8/CF8M

SINGLE ACTING AIR RELEACE VALVE ( LARGE ORIFICE )

For automatically releasing/admitting air that may accumulate under pressure in a section of ripe line at the time of initial charging or draining of mains.

Specifications

Brand                                  : Floin

Model                                  : AR102

Size                                      : 25 TO 50 NB

Connection                      : Flanged/screwed

Mounting                          : Top

Material                             : CI/WCB/CF8/CF8M
